Image is for reference, please contact us to get the real picture
| Manufacturer Part Number: | CX2520SB13560D0GEJZ1 |
| Manufacturer: | KYOCERA Corporation |
| Part of Description: | CRYSTAL 13.5600MHZ 8PF SMD |
| Lead Free Status / RoHS Status: | Lead Free / RoHS Compliant |
| Stock Condition: | 3253 In Stock |
| Ship From: | Hong Kong |
| Shipment Way: | DHL/Fedex/TNT/UPS/EMS |
| Type | Description |
|---|---|
| Series | CX2520SB, Kyocera |
| Package | Tape & Reel (TR)Cut Tape (CT)Digi-Reel® |
| Part Status | Obsolete |
| Type | MHz Crystal |
| Frequency | 13.56 MHz |
| Frequency Stability | ±15ppm |
| Frequency Tolerance | ±15ppm |
| Load Capacitance | 8pF |
| ESR (Equivalent Series Resistance) | 150 Ohms |
| Operating Mode | Fundamental |
| Operating Temperature | -10°C ~ 70°C |
| Ratings | - |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension | 0.098" L x 0.079" W (2.50mm x 2.00mm) |
| Height - Seated (Max) | 0.022" (0.55mm) |
Stock Status: 3253
Minimum: 1
Call for price or submit a RFQ
